Architecture First
We start with the packet path—not feature lists or buzzwords.
Turn OPNsense into a Real Next-Generation Firewall
Built for engineers who demand more than plugins. No buzzwords. No black boxes. Just architecture, performance, and control.
Built by engineers. Explained like engineers expect.
Performance Matters
Throughput and latency are design constraints, never afterthoughts.
No Black Boxes
How it works, what it inspects, and where it fails is fully documented.
Why We Exist
Why most NGFW plugins hit a wall
Open-source firewalls are powerful, but bolted-on security features often trade performance for visibility. We built a security engine that integrates with the packet path instead of fighting it.
Meet the team behind Zedmos →Inline capabilities
What the engine enforces without leaving the packet path
Every control runs inside the same inspection pipeline—no bolted-on daemons, no policy gaps, no extra hops.
TLS / SSL Inspection
Decrypts HTTPS, SMTPS, FTPS, and other TLS flows inline so malware and exfiltration attempts are caught where they start.
- Man-in-the-Middle (MitM) decryption
- Policy-based SNI bypass (Banking, Gov)
- Supports TLS 1.2 and 1.3
Application Control
Identifies thousands of applications (BitTorrent, WhatsApp, Tor, YouTube) regardless of port using nDPI.
- Layer-7 traffic classification
- Block P2P, VPNs, and proxies
- Granular category-based rules
Threat Intelligence
Blocks malicious domains, botnet C2s, and phishing sites instantly with feeds from USOM, URLhaus, OpenPhish, and ThreatFox.
- Automated feed updates
- Zero-configuration protection
- Real-time blocking of new threats
Inline File Scanning
Scans HTTP/S, FTP, SMTP, and SMB transfers with ClamAV before payloads land, keeping endpoints clean.
- Scan inside encrypted archives
- MIME-type aware filtering
- Optional ICAP & YARA support
Web & DNS Filtering
Enforces URL and DNS policies, including DoH/DoQ controls, so acceptable use policies stick.
- Block adware & tracking
- Prevent DNS tunneling
- Baseline WAF protections
Identity & Device Aware
Applies policy per user, device type, or geography and isolates compromised assets automatically.
- User-to-IP mapping
- Device fingerprinting (MAC/OUI)
- Runtime risk tagging & quarantine
Architecture Overview
Designed Around the Packet Path
This is not a feature collection; it is a security engine. Packets enter via netmap, stay in shared memory through DPI + TLS analysis, and exit only after synchronous policy evaluation. Storage and control-plane hooks are fed via writerd, not by bolting on scripts.
- Optimized inspection pipeline
- Minimal context switching
- Zero-copy packet handling
- NIC offloading aware design
- nDPI + TLS analyzer feeding policy runtime
- Writerd log plane (SQLite / Elastic / Mongo)
NIC / Netmap Capture
Zero-copy RX/TX rings, per-queue workers, takeover-aware interfaces.
DPI + TLS Analyzer
nDPI classification, TCP reassembly, JA3/JA4 fingerprints, TLS MITM.
Policy Runtime
Suffix tries, TI cache, identity selectors, synchronous enforcement.
Action Layer
Allow/block, tls_bump/bypass, shadow/quarantine, StartTLS handling.
Writerd / Storage
Writer daemon → SQLite/Elastic/Mongo via zero-copy ring & batching.
Control Plane
UNIX socket RPC, hot reload worker, metrics/export knobs.
Architecture is the product. Traffic never leaves this pipeline.
Performance Is a Feature
Security engines are measured under load
Real security maintains throughput, keeps latency predictable, and avoids CPU thrash even when inspection is fully enabled.
Comparison
Why Zedmos replaces plugin stacks
Plugin chains chase features after traffic leaves the NIC. Zedmos stays inline—from netmap capture through policy runtime—so latency, CPU, and telemetry stay deterministic.
| Dimension | Plugin stack | Zedmos engine |
|---|---|---|
| Model | Security plugin chain | Zedmos inline engine |
| Architecture focus | Feature backlog & UI | Packet-path & determinism |
| Inspection path | Add-on detour after routing | Integrated netmap → policy |
| Performance priority | Shared CPU budget | Primary design goal (line-rate) |
| Policy execution | Per-plugin hooks | Single runtime w/ suffix tries |
| Telemetry | Syslog/export scripts | Writerd log plane (SQLite / ES / Mongo) |
Built for
- OPNsense power users
- Security engineers
- MSPs / MSSPs
- High-throughput environments
Not for
- One-click security buyers
- Black-box stacks
- Feature-only comparisons
- Marketing-driven deployments
